TUV 2 PFG 1169 PV1-F Photovoltaic system cable Solar Cable Single copper core Photovoltaic systcable
$49.22
$94.01
The Solar cable is used for cabling solar modules. Suitable for direct burial. Recommendation: Laying in pipe. Conductor Tinned copper conductor, fine wire acc. to DIN VDE 0295 cl.5 / IEC 60228 cl.5 Core insulation special crosslinked compound Core identification DIN 47100,without colour repetition Outer sheath special crosslinked compound Sheath colour see Attachment Packaging Meter marking Test voltage AC 6,5 kV Operating peak voltage at the conductor 120°C Temperature range -40°C to 90°C Minimum bending radius fixed installation 5x outer Ø Details Conductor copper Color Gray MOQ 500meter Nominal voltage U0/U AC : 1,0/1,0 kV DC : 1,5/1,5 kV Temperature (°C) - fixed -40 to 80℃ Temperature (°C) - flexing -40°C to 90°C
Single Core Cable
